BS40

Types:Excavators

Tel/Whatsapp: +86 13081631265
Product details










Advantages and highlights:

* More energy-conservation and environmental protection By adopting Yanmar enginemeeting national stage III emission standard,mechanical fuel injection pump has reliable performance. With compact size, the maintenance is convenient. Enough low torque reserve can ensure strong power. High reliability can reduce the maintenance cost.

*  More efficient return Rear-end swing radius adopts tailless design, which can ensure that the tail part will not collide with obstacles under narrow working conditions.Deflectable working device can deflect to left and right at 75° and 50° separately, which can achieve compound action with superstructure. Through swing cooperation with superstructure, digging operation parallel to the wall surface will be achieved and various kinds of working conditions can be coped with easily.



ModelBS40
SpecificationsWeight of the whole machine3650kg
Whole machine size4560*1550*2500mm
Bucket capacity0.09m³
Bucket width550mm
Track length2105mm
Track width300mm
Height of platform590mm
PerformanceSlewing speed10rpm
Walking speed4.6km/h
Bucket digging force15.6KN
EngineEngine ModelYanmar3TNV88
Engine power19.6KW
Engine speed rating2400r/min
Hydraulic system pressure21mpa
Scope of workMaximum excavation radius4840mm
Maximum excavation depth3140mm
Maximum excavation height3050mm
Tail turning radius885mm
