Our excavators drive through a fully automatic hydrostatic powershift transmission and heavy-duty axles, providing fast travel speed between working sites and excellent traction. An improved orbit steering system delivers effortless and precise control. A larger steering angle makes it even easier to move in confined areas. Multi-disc wet brakes dual circuit system with oil immersed brakes on all wheels.
Types：Excavators
Improved Engine Performance
Wheel excavators can be used for a variety of tasks and in different jobsite environment, and the engines used in these machines are designed to be flexible and adaptable to different types of work. It can help reduce operating costs while make the machine more environmentally friend
Hydraulic System
Adopt world famous brand hydraulic pump, distribution and control valves, the advantages of our excavator hydraulic systems make them an essential components of modern excavation equipment, providing increased power, efficiency, and versatility to operators.
| Model | BS90W | |
| Whole machine size | 6400*2120*2900mm | |
| Bucket capacity | 0.3m³ | |
| Boom length | 3500mm | |
| Height of platform | 1060mm | |
| Wheel base | 2350mm | |
| Performance | Slewing speed | 11.5rpm |
| Walking speed | 35km/h | |
| Bucket digging force | 60KN | |
| Engine | Engine Model | Yuchai4DK65-T303 |
| Engine power | 48KW | |
| Engine speed rating | 2200r/min | |
| Hydraulic system pressure | 22mpa | |
| Scope of work | Maximum excavation radius | 6400mm |
| Maximum excavation depth | 3550mm | |
| Maximum excavation height | 4800mm | |
| Maximum excavation radius | 6800mm | |
| Max.sinkin depth of buldozer | 330mm | |
| Max.lift height of buldozer | 300mm | |
