9HP
Types：Lawn Mowers
Configuration and Features:
(1) The power adopts the Longxin gasoline engine, the gasoline-electric hybrid power, and the SKK55 type comes with the power generation and power supply system, which has an automatic charging during the process of work.
(2) It is driven by a motor and can achieve zero-turn work.
(3)It has an engineering grade remote device, which can achieve simple operation and low failure rate. And the maximum remote control distance is 200 meters.
(4) The steel frames and wires on the inside of the machine and the engineered rubber on the outside make it durable.
(5) Low fuselage, tank design, good climbing ability. Especially suitable for: orchards, hills, terraces, and grass cutting.
(6) Weeding height (3-12cm) and speed can be adjusted by remote control.
Technical Parameters:
Number | Project name | Unit | Parameter values | |
1 | Main engine | model | BS55 | |
Overall dimension (length, width and height) | mm | 900*900*560 | ||
Weight | kg | 120 | ||
Track width | mm | 120 | ||
2 | Supporting power | Manufacturing enterprise | Longxin General Power Co., Ltd | |
Model name | LC1P75F-1 | |||
Structural type | Single bar four stroke | |||
Maximum power | Ps | 9 | ||
Rated speed | r/min | 3600 | ||
Fuel types | gasoline | |||
Average fuel consumption | L/h | 1-1.5 | ||
Displacement | cc | 224 | ||
3 | Walking motor | Power rating | Kw | 1.2 |
Working voltage | V | 24 | ||
Speed | r/min | 1000~3000 | ||
Speed of travel | Km/h | 0~5 Adjustable | ||
Remote control distance | m | ≤200 | ||
Work slope | Degree | ≤45 | ||
4 | Dynamo | Power rating | KW | 1.5 |
5 | Storage battery | Battery type | dry-charged battery | |
Remote control battery voltage | V | 24 | ||
Walking battery voltage | V | 24 | ||
Charging type | Charge automatically when the generator is working | |||
6 | Supporting lawn cutting tools | Number of blades | Piece | 2 |
Knife speed | r/min | 2000-3000 | ||
Wearing width | mm | 550 | ||
The height of the grass | mm | 30~120 Adjustable | ||
