BSC
Types：Cultivators
Technical Parameters
| Number | Item | |||||||
| 1 | Machine | Model | BSC | |||||
| Measurement(L*W*H) | mm | 1550*400*640 | ||||||
| Weight | kg | 100-130 | ||||||
| Walking gear | neutral positiobn, 2 forward gears,1reverse gear | |||||||
| Working gear | 2 gears | |||||||
| Starting method | / | hand/electric | ||||||
| Linkage | direct connection | |||||||
| Driving method | rotary self-propelled | |||||||
| 2 | Power | Engine | 170 gasoline/173 diesel | |||||
| Fuel | / | gasoline/engine | ||||||
| Efficiency | （mu/h） | 1-1.5 | ||||||
| Fuel consumption | （L/h） | 0.7-1.2 | ||||||
| Knife-cylinder speed | r/min | 280-500 | ||||||
| Working speed | (km/h) | ≥0.5 | ||||||
| 3 | Function | weeding, rotary tillage, ridger, backfill | ||||||
| Application | Farm, Garden, Lawn and Home use | |||||||
Accessories and Details
| Configuration | Number | Function | Value | ||||
| Standard | 1 | Rotary tillage | width | 70-80cm | |||
| depth | 15-20cm | ||||||
| 2 | Weeding | width | 70-80cm | ||||
| 3 | Trencher | depth | 15-20cm | ||||
| width | 15-20cm | ||||||
| Optional | 1 | Backfill | width | 60-80cm | |||
| 2 | Ridger | width | 40-60cm | ||||
| 3 | Mower | width | 65cm | ||||
| 4 | Plough | depth | 5-10cm | ||||
